| Price | Negotiable |
| MOQ | 1 Kilometer |
| Delivery Time | 2-5days |
| Brand | JQ/OEM |
| Place of Origin | Guangdong, China |
| Certification | CE/ISO9001 |
| Model Number | ADSS |
| Packaging Details | Wooden Drum |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability | 8000 kilometers per month |
| Central strength member | FRP | Fiber count | 2-288 Cores |
| Jacket | PE,MDPE,LSZH,PVC | Place of Origin | Guangdong, China |
| Packaging Details | Wooden Drum | Color | Customized |
| Model Number | ADSS | Supply Ability | 8000 kilometers per month |
| Certification | CE/ISO9001 | Brand Name | JQ/OEM |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union | Type | Outdoor Fiber Optic Cable |
| Delivery Time | 2-5days | Length | as required |
| Oem | Available | Minimum Order Quantity | 1 Kilometer |
| Package | Wooden Drum/Customized | Structure | Multi Loose Tube |
| Application | Self-supporting aerial | Fiber type | G652D Single mode or as your request |
| Number of Conductors | ≥ 10 |
Specification:
| item | value |
| Model Number | ADSS |
| Type | Outdoor Fiber Optic Cable |
| Place of Origin | Guangdong,China |
| Brand Name | jiqian |
| Cable type | Outdoor All dielectric self-supporting aerial cable ADSS |
| Cable Structure | FRP+aramid yarn+outher sheath |
| Number of Conductors | ≥ 10 |
| Fiber count | 2-144 Cores |
| Fiber material | silicon dioxide |
| Fiber Type | G652D Single mode or as your request |
| Fiber color | Blue, Orange, Green, Brown,etc |
| Central strength member | FRP |
| Loose tube | Jelly filled |
| Loose Tube | Stranded Loose Tube |
| Loose tube Material | PBT |
| Water Blocking | Water Swell able Material |
| Jacket Sheath | PE |
| Color | Black or as your need |
| Package | Plywood Reel/customized |
| Installation | Self-supporting aerial |
| Span | 150 meters |
| operating temperature | -40 to +70 |
| Certification | CE/ROHS/ISO9001 /ANATEL |
Optical Characteristics:
| G.655 | 50/125μm | 62.5/125μm | ||
| G.652 | ||||
| Attenuation | '@850nm | ≤3.0 dB/km | ||
| (+20℃) | '@1300nm | ≤1.0 dB/km | ||
| '@1310nm | ≤0.34 dB/km | ≤0.40 dB/km | ||
| '@1550nm | ≤0.21 dB/km | ≤0.23 dB/km | ||
| '@850nm | ≥500 MHz·km | |||
| '@1300nm | ≥1000 MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | |||
